About Us
Carve Dies, was Established in 1994 as a Small Unit in Mumbai.
The very first toolroom size was 10x10 (foot) room, with a small lathe machine & drilling machine.
From Scrap This Firm is been developing By Dedication, Handwork & Hard Work By the Whole Team.
Tool and die makers are highly skilled crafters working in the manufacturing Industries Variations on the name include tool maker, toolmaker, die maker, diemaker, depending on which area of concentration or industry an individual works in
Tool and die makers work primarily in toolroom environment sometimes literally in one room but more often in an environment with flexible, semipermeable boundaries from production work.
OUR TEAM WORKING PATTERN...
PRODUCT DESIGN
The definition of product design describes the process of imagining, creating, and iterating products that solve users' problems or address specific needs in a given market. The key to successful product design is understanding the end-user customer, the person for whom the product is being created.
MOULD DESIGN
Injection moulding is a formative manufacturing technology, i.e. material is formed from an amorphous shape into a fixed shape defined by a mould tool.
STEEL PROCUREMENT
Material procurement is the process of researching, selecting, ordering, and paying for the raw materials required for developing a New Mold
CNC MACHINING
Numeric control is the automated control of machining tools by means of a computer. A CNC machine processes a piece of material to meet specifications by following coded programmed instructions and without a manual operator directly controlling the machining operation
.
EDM MACHINING
Electrical discharge machining (EDM), also known as spark machining, spark eroding, die sinking, wire burning or wire erosion, is a metal fabrication process whereby a desired shape is obtained by using electrical discharges.
FITTING & ASSEMBLY
Mold assembly is one of the most critical steps of mold making procedure, all the parts machined or purchased need to be put together and required to be work functionality. Mold assembly job requires comprehensive understanding of mold structure as well as injection molding.
POLISH
Plastic injection mold polishing is a technique that helps to obtain smooth mold surfaces. It does this by removing the convex parts of the mold through plastic deformation and cutting. Generally, mold polishing techniques use wool wheels, whetstone strips, and sandpaper for manual polishing.
FINAL INSPECTION
- Injection. When the two plates of the mold are clamped together, injection can begin.
- Dwelling. In the dwelling phase, the melted plastic fills the entirety of the mold.
- Cooling.
- Mold Opening.
- Ejection.
TRIAL
Mold Trial is conducted when 100% of the work is completed , we suggest a suitable injection molding machine as required for the mold made.
The process parameters & other necessary details would be shared to the customer while taking production.
